Semikron 1500V Solar Applications
Published on: 05/12/2017
Semikron 1500V solar applications, featuring power modules, IPMs and power electronic stacks
GD Rectifiers have been distributing Semikron semiconductors for over 50 years, today we are considered the go-to distributor of power components across a wide range of markets.
Product Overview of 3-level Modules for Semikron 1500V Solar Applications
| NPC | SEMITOP MLI | 1200V | 20A up to 150A |
| MiniSKiiP MLI | 1200V | up to 150A | |
| SKiM 4 MLI | 1200V | 300A up to 600A | |
| SEMiX MLI | 1200V | 200A up to 300A | |
| SEMITRANS 10 | 1200V | up to 1200A | |
| T-NPC | SKiM 4 TMLI | 1700V/1200V | up to 300A |
| SEMiX 5 TMLI | 1700V/1200V | 200A up to 300A |
Power Modules for 1500V Applications
- Broad portfolio of 2-level and 3-level modules
- Up to 750Kw without paralleling with SEMITRANS10
- All connection technologies available: solder pins, press-fit pins, screw connector and spring contacts
- Plug and play drivers
IPMs for 1500V Applications
- Dedicated SKiiP 4 version for 1500V PV applications
- Water-and air cooled versions
- CANopen interface for diagnostics
- Maximum reliability thanks to Single Sided Sintering technology and SEMIKRON ASIC driver chipset
- 100% tested including burn-in test
Stacks for 1500V Applications
- Fast time-to-market with ready to use power stacks
- Customised designs for individual customer applications
- Including SEMIKRON drivers with ASIC chipset for maximum reliability
- UL certification
- IntelliOff function for 1500V DC voltage
Key Features
- Comprehensive portfolio from power modules to IPMs and complete power stacks
- Comprehensive product line of 3-level power modules
- Large power range including multi-megawatt inverters
- Fast time-to-market with ready to use power stacks
- Flexible design for customised stacks
- Maximum power density up to 5.7kVA/litre
