AC Controller Thyristors
IXYS AC controller thyristors range from 30-650A. The AC controller thyristor is designed to provide electrical isolation between the base plate of the module and the parts, subject to voltage conventional multilayer module construction by the direct copper bonding (DCB) technique.
Need components urgently and looking for stock?
Discover our stock list and shop from over 170,000 components from 150 different product lines.
IXYS AC Controller Thyristors
IXYS offer a wide range of AC controller thyristors ranging from 30-650A. The thyristor is designed to provide elctrical isolation between the base plate of the module and the parts, subject to voltage conventional multilayer module construction by the direct copper bonding (DCB) technique. IXYS’ AC controller modules are available in two standardised twin plugs for gate and auxiliary cathode control terminals. The AC controller modules feature: direct copper bonded AI203-ceramic, excellent long-term stability of blocking currents and blocking voltages and planar passivated chips.
They are used in a wide raage of applications including: motor drive and control, lighting and power management.
AC Controller Thyristors
Irms = 30-230A
| Type
|
Vrrm
Vdrm V |
Itav
A |
Irms
A |
@Tc
C |
Itsm
45°C 10ms A |
VT0
V |
rT
mΩ |
Tvjm
°C |
RthJC
K/W |
RthJH
K/W |
Fig No.
|
| MMO 62-12io6 | 1200 | 400 | 66 | 95 | 400 | 0.87 | 13.6 | 150 | 0.90 | 1.10 | X027a |
| MMO 62-16io6 | 1600 | 500 | 66 | 95 | 400 | 0.87 | 13.6 | 150 | 0.90 | 1.10 | X027a |
| MMO 74-12io6 | 1200 | 400 | 88 | 95 | 600 | 0.87 | 10.5 | 150 | 0.70 | 0.80 | X027a |
| MMO 74-16io6 | 1600 | 500 | 88 | 95 | 600 | 0.87 | 10.5 | 150 | 0.70 | 0.80 | X027a |
| MMO 90-12io6 | 1200 | 400 | 110 | 95 | 800 | 0.88 | 6.0 | 150 | 0.60 | 0.70 | X027a |
| MMO 90-14io6 | 1400 | 440 | 110 | 95 | 800 | 0.88 | 6.0 | 150 | 0.60 | 0.70 | X027a |
| MMO 90-16io6 | 1600 | 500 | 110 | 95 | 800 | 0.88 | 6.0 | 150 | 0.60 | 0.70 | X027a |
| CLA 110MB1200NA | 1200 | 400 | 110 | 110 | 1100 | 0.78 | 4.9 | 150 | 0.55 | 0.65 | X027a |
| MMO 110-12io7 | 1200 | 400 | 112 | 85 | 1000 | 0.85 | 5.6 | 150 | 0.80 | 0.92 | X101 |
| MMO 110-14io7 | 1400 | 440 | 112 | 85 | 1000 | 0.85 | 5.6 | 150 | 0.80 | 0.92 | X101 |
| MMO 140-12io7 | 1200 | 400 | 130 | 85 | 1150 | 0.85 | 5.2 | 150 | 0.70 | 0.82 | X101 |
| MMO 140-16io7 | 1600 | 500 | 130 | 85 | 1150 | 0.85 | 5.2 | 150 | 0.70 | 0.82 | X101 |
| MMO 175-12io7 | 1200 | 400 | 175 | 85 | 1500 | 0.85 | 3.7 | 150 | 0.50 | 0.62 | X101 |
| MMO 175-16io7 | 1600 | 500 | 175 | 85 | 1500 | 0.85 | 3.7 | 150 | 0.50 | 0.62 | X101 |
| MMO 230-12io7 | 1200 | 400 | 230 | 85 | 2250 | 0.80 | 2.4 | 125 | 0.26 | 0.46 | X102 |
| MMO 230-16io7 | 1600 | 500 | 230 | 85 | 2250 | 0.80 | 2.4 | 125 | 0.26 | 0.46 | X102 |
| VW 2×60-12io1 | 1200 | 400 | 2x 60 | 85 | 520 | 0.85 | 11.0 | 125 | 0.92 | 1.22 | X103 |
| VW 2×60-14io1 | 1400 | 440 | 2x 60 | 85 | 520 | 0.85 | 11.0 | 125 | 0.92 | 1.22 | X103 |
| VW 2×60-16io1 | 1600 | 500 | 2x 60 | 85 | 520 | 0.85 | 11.0 | 125 | 0.92 | 1.22 | X103 |
| VWO 35-08ho7 | 800 | 250 | 3x 35 | 85 | 200 | 0.85 | 27.0 | 125 | 1.30 | 1.80 | X101 |
| VWO 35-12ho7 | 1200 | 400 | 3x 35 | 85 | 200 | 0.85 | 27.0 | 125 | 1.30 | 1.80 | X101 |
IXYS’ Triac design is the combination of two thyristor technologies, instead of using two back to back thyristors with two separated gates, IXYS uses proprietary anode gated thyristor technology to integrate AC controllers with two complementing as one lead.
The Triac design offers superior performance and is used in numerous power control design applications.
Triac
Irms = 30-650A
| Type
|
Vrrm
Vdrm V |
Itav
A |
Tc
°C |
It(rms)
A |
Itsm
45°C 10ms A |
VT0
V |
rT
mΩ |
Tvjm
°C |
RthJC
K/W |
RthCH
K/W |
Fig No.
|
| CLA 30MT1200NPB | 1200 | 400 | 33 | 120 | 170 | 0.89 | 30.5 | 150 | 0.95 | 1.45 | X005a |
| CLA 30MT1200NPZ | 1200 | 400 | 33 | 120 | 170 | 0.89 | 30.5 | 150 | 0.95 | 1.20 | X011c |
| CLA 40MT1200NPB | 1200 | 400 | 44 | 110 | 180 | 0.89 | 27.9 | 150 | 0.80 | 1.30 | X005a |
| CLA 40MT1200NPZ | 1200 | 400 | 44 | 110 | 180 | 0.89 | 27.9 | 150 | 0.80 | 1.05 | X011c |
| CLA 40MT1200NHB | 1200 | 400 | 44 | 110 | 180 | 0.89 | 27.9 | 150 | 0.80 | 1.05 | X014a |
| CLA 40MT1200NHR | 1200 | 400 | 44 | 95 | 180 | 0.89 | 27.9 | 150 | 1.30 | 1.55 | X016c |
| CLA 60MT1200NHB | 1200 | 400 | 66 | 120 | 380 | 0.86 | 12.5 | 150 | 0.55 | 0.80 | X014a |
| CLA 60MT1200NTZ | 1200 | 400 | 66 | 120 | 380 | 0.86 | 12.5 | 150 | 0.55 | 0.70 | X019a |
| CLA 60MT1200NHR | 1200 | 100 | 0.90 | 1.15 | X016c | ||||||
| CMA 60MT1600NHB | 1600 | 500 | 66 | 115 | 260 | 0.90 | 16.6 | 150 | 0.55 | 0.80 | X014a |
| CMA 60MT1600NHR | 1600 | 90 | 0.90 | 1.15 | X016c | ||||||
| CLA 80MT1200NHB | 1200 | 400 | 88 | 120 | 480 | 0.85 | 9.2 | 150 | 0.40 | 0.65 | X014a |
| CLA 80MT1200NHR | 1200 | 400 | 88 | 100 | 480 | 0.85 | 9.2 | 150 | 0.65 | 0.90 | X016c |
| CMA 80MT1600NHB | 1600 | 400 | 88 | 115 | 400 | 0.90 | 12.0 | 150 | 0.40 | 0.65 | X014a |
| CMA 80MT1600NHR | 1600 | 500 | 88 | 95 | 400 | 0.90 | 12.0 | 150 | 0.65 | 0.90 | X016c |
| MCMA 650MT1400NKD | 1400 | 440 | 650 | 85 | 9600 | 0.81 | 0.68 | 140 | 0.12 | 0.04 | X132a |
| MCMA 650MT1800NKD | 1800 | 575 | 650 | 85 | 9600 | 0.81 | 0.68 | 140 | 0.12 | 0.04 | X132a |
