Images are for reference only, see product specifications for full details
SKPC 350-415 Trigger Module
The SKPC 350-415 thyristor trigger module is designed for controlling either a W3C AC/AC full control or W3H half control configurations.
- Controls a wide range of thyristors
- Logic control
- Optional current limit
- Soft start/stop, adjustable ramp up/down periods
- Fully isolated input from output
- Wide selection of supply voltages
A wide range of different supply voltages are available as standard units. An isolated relay output is used for indicating when current limit is in action.
Approvals
RoHS Compliant
Typical Applications
- Heating loads
- Power supplies
- High in-rush current loads
- DC injection braking
- Motor control
Refer to manufacturer’s datasheet for full technical information.
| Manufacturer | |
|---|---|
| Applications | DC Injection Braking, Heating loads, High in-rush current loads, Motor Control, Power Supplies |
| Input Voltage | 0-15V |
| Impedance | 100K ohm min |
| Maximum Input | 25Vdc |
| Current (A) | 4-20mA |
| Aux 10V Output | 10V +/-5%, 3mA max |
| Supply Frequency | 47 to 63Hz |
| Operating Temperature (Top) | 0°C to +50°C |
| Product Type | Thyristor Trigger Module |
