IXYS UK Westcode Press Pack IGBTs

Published on: 07/04/2017

Discover the complete range of IXYS UK Westcode’s Press Pack IGBTs (Insulated Gate Bipolar Transistors)

IXYS UK Westcode offer a large range of press pack IGBT devices with voltage ratings of 1.7kV (900V DC link), 2.5kV (1.25kV DC link) and 4.5kV (2.8kV DC link). The assembly of these devices is free from wire and solder bonds which eliminates the problems of mechanical fatigue associated with conventional modules.

These devices are based on a state-of-the-art punch through process which yields exceptional values VCE(sat) and quiet switching behaviour despite the high voltage ratings, yet the devices feature a positive temperature coefficient making them suitable for reliable parallel operation. IXYS UK Westcode devices are available with or without integral anti-parallel diode; a range of complimentary extra fast recovery diodes optimised for use with these IGBTs are available now with more based on exciting new technologies coming soon.

Typical applications include: HVDC, active VAr controllers and medium voltage drives. They are largely compatible with standard 2.5kV and 4.5kV GTOs in many applications such as AC drives. These parts are a simple and economical solution to upgrade or refurbish equipment that previously used GTOs, such as locomotives or medium voltage drives. They are suitable for cooling options including direct liquid immersion.

Press Pack IGBTs (Capsules)

Please click on the part numbers below to view the datasheet.

Press Pack IGBT (Gate Drive Units)

Features

1. High reliability topology

2. Designed for ultra low power consumption

3. Built in DC/DC converter with soft start

4. Integrated input filter for low EMI

5. Separate low impedance path for parasitic EMI currents

6. PD-Voltage levels available up to 11kV on request

7. Low impedance from gate to emitter at start-up and power fail

8. Monitoring of all secondary supply voltages

9. Monitoring of IGBT switching status (VCE de-sat detection)

10. Soft switch-off at VCE de-sat fault condition

11. Fibre-optic links for switching commands and status control

12. Low light protection for input signal

13. Short-pulse suppression, configurable

14. Balanced propagation delay time

15. Gate current up to 44A

16. Optional gate speed-up capacitors

Application

1. Large and medium drives

2. Renewable generation

3. Utilities scale converters

IGBT Gate Drives Brochure

IGBT Gate Drive Boards Datasheet

GD Rectifiers is a Global Manufacturer and Distributor of products, services and solutions to commercial and industrial users of power electronic components. GD Rectifiers are an official distributor for both IXYS and IXYS UK Westcode.

For further information on all IXYS Press-Pack IGBTs please contact our team on: 01444 243 452 / [email protected].
