June 2017 – GD Rectifiers’ Range of Thyristors
Published on: 12/06/2017
Introducing GD Rectifiers extensive range of thyristors
GD Rectifiers distributes a wide variety of reliable high power semiconductors using conventional and future technologies. They design and manufacture selenium and silicon rectifier diodes, suppressors, converters, inverters, and regulator products for Industrial power control applications.
We are the UK’s leading distributor for semiconductor components; state of the art Diodes, Thyristors, IGBT Modules and MOSFETs from the world’s greatest manufacturers including: IXYS, IXYS UK Westcode, Semikron and EDI. They stock a wide range of Thyristors from the world’s leading semiconductor manufacturers.
GD Rectifiers Thyristors
GD Rectifiers manufactures range of low loss, high efficiency phase controlled thyristors. Applications include wind turbines, soft start, traction and heating. Our range is from 750Amps to 4000Amps and a table of the devices can be seen below.
| Part Number | Vdrm, Vrrm | Itav, TC = 55°C |
| GDT751/18 | 1800 | 795 |
| GDT751/22 | 2200 | 530 |
| GDT1100/26 | 2600 | 910 |
| GDT1100/36 | 3600 | 646 |
| GDT1250/18 | 1800 | 1240 |
| GDT1800/16 | 1600 | 1802 |
| GDT1800/20 | 2000 | 1718 |
| GDT1800/26 | 2600 | 1467 |
| GDT1800/36 | 3600 | 1314 |
| GDT2500/16 | 1600 | 2500 |
| GDT2500/22 | 2200 | 2293 |
| GDT2500/36 | 3600 | 1661 |
| GDT3500/22 | 2200 | 3533 |
| GDT3500/36 | 3600 | 2418 |
| GDT4000/12 | 1200 | 4085 |
Obsolete Thyristor Replacements
GD Rectifiers can manufacture a large range of flat base conversion kits used to replace obsolete flat based thyristors.
For further information on Obsolete Semiconductor replacements please click here.
IXYS Thyristors
IXYS offer a wide range of Thyristor modules and Discrete Phase Control Thyristors ranging from 16A to 700A with a voltage range of 100V to 2200V.
IXYS UK Westcode Thyristors
IXYS UK Westcode provide a comprehensive range of standard phase control thyristors, devices range from 600V to 4500V making them suitable for applications with line voltages from 230V to over 1000V.
View IXYS UK Distributed Gate Thyristors
View IXYS UK Fast Turn-off Thyristors
View IXYS UK Medium Voltage Thyristors
SEMIKRON Thyristors
SEMIKRON manufacture an extensive range of discrete thyristors available as stud screw or capsule types. They feature current ratings up to 1200a with blocking and reverse voltages up to 1800V.
For further information on Thyristors please call: 01444 243 452 or email: enquiries@gdrectifiers.co.uk.
